Switch Amplifier KHA6-SH-Ex1

·         1-channel isolated barrier

·         115/230 V AC supply

·         Input for approved dry contacts or SN/S1N sensors

·         Relay contact output

·         Fault indication output

·         Line fault detection (LFD)

·         Up to SIL 3 acc. to IEC 61508

·         Up to PL d acc. to EN/ISO 13849

Function :

This isolated barrier is used for intrinsic safety applications. The device transfers digital signals (SN/S1N proximity sensors or approved dry contacts) from a hazardous area to a safe area.

The input controls one output with 3 form A normally open relay contacts (one is in series to the 2 output relay contacts for the safety function),

one output with 1 form A normally open relay contact, and one passive transistor output.

Unlike an SN/S1N series NAMUR proximity sensor, a mechanical contact, requires a 10 kilohm resistor to be placed across the contact in addition to a 1.5 resistor in series.

Lead breakage (LB) and short circuit (SC) conditions of the control circuit are continuously monitored.

During an error condition, fault output energizes and outputs I and II de-energize.

For safety applications up to SIL3, output I must be used.
