PEPPERL+FUCHS HOT SELL Switch Amplifier KCD2-ST-Ex1.LB Intrinsic Safety Barriers Isolated Barriers K-System

New & Original
KCD2-ST-Ex1.LB
PEPPERL+FUCHS HOT SELL Switch Amplifier KCD2-ST-Ex1.LB Intrinsic Safety Barriers Isolated Barriers K-System
Please contact us for more information.

PEPPERL+FUCHS Switch Amplifier KCD2-ST-Ex1.LB Intrinsic Safety Barriers Isolated Barriers K-System





Switch Amplifier KCD2-ST-Ex1.LB


1-channel isolated barrier

24 V DC supply (Power Rail)

Dry contact or NAMUR input

2 active transistor outputs

Usable as signal splitter (1 input and 2 outputs)

Reversible mode of operation

Line fault detection (LFD)

Housing width 12.5 mm

Up to SIL 2 acc. to IEC 61508


Function :

This isolated barrier is used for intrinsic safety applications. The device transfers digital signals (NAMUR sensors or dry contacts)

from a hazardous area to a safe area. The input controls two active transistor outputs. Via switches the mode of operation

can be reversed and the line fault detection can be switched off.

Via switch the function of the second output can be defined as a signal output or an error output.

A fault is signalized by LEDs acc. to NAMUR NE44 and a separate collective error message output.




Selection models:

KCD2-SR-Ex1.LB                                      KCD2-SR-Ex2                                KFA6-DU-Ex1.D

KFA6-ER-Ex1.W.LB                                  KFA6-SOT2-Ex2                             KFA6-SR2-Ex1.W

KFA6-SR2-Ex1.W.LB                                KFA6-SR2-Ex2.W                           KFA6-SR2-Ex2.W.IR

KFD2-DU-Ex1.D



KFD2-ELD-Ex16                                       KFD2-ER-Ex1.W.LB                         KFD2-SH-Ex1

KFD2-SH-Ex1.T.OP                                  KFD2-SOT3-Ex1.LB                         KFD2-SOT3-Ex1.LB.IO

KFD2-SOT3-Ex2                                       KFD2-SOT3-Ex2.IO                         KFD2-SR2-Ex1.W

KFD2-SR2-Ex1.W.LB



KFD2-SR2-Ex2.W                                    KFD2-SR3-Ex2.2S                           KFD2-SRA-Ex4

KFD2-ST3-Ex1.LB                                   KFD2-ST3-Ex2                                 KHA6-SH-Ex1

KCD2-SON-Ex1                                       KCD2-SOT-Ex1.LB                           KCD2-SOT-Ex2

KCD2-SOT-Ex2.SP



KCD2-SR-Ex1.LB.SP                               KCD2-SR-Ex2.SP                             KCD2-ST-Ex1.LB

KCD2-ST-Ex2                                          KFA5-SOT2-Ex2                               KFA5-SR2-Ex1.W

KFA5-SR2-Ex1.W.LB                               KFA5-SR2-Ex2.W                             KFA5-SR2-Ex2.W.IR

KFD2-SH-Ex1.T



KFD2-SOT3-Ex2.IO-Y1                          KCD2-SON-Ex1.R1                         KCD2-SON-Ex1.SP

KCD2-SON-Ex2                                      KCD2-SON-Ex2.R1                         KCD2-SON-Ex2.SP

KCD2-SOT-Ex1.LB.SP                           KCD2-ST-Ex1.LB.SP                        KCD2-ST-Ex2.SP

KFA4-SR2-Ex2.W




实拍_副本_副本
