PEPPERL+FUCHS Switch Amplifier KCD2-SON-Ex1.R1Intrinsic Safety Barriers Isolated Barriers K-System

Switch Amplifier KCD2-SON-Ex1.R1

·         1-channel isolated barrier

·         24 V DC supply (Power Rail)

·         Dry contact or NAMUR input

·         2 passive transistor outputs (resistive)

·         Application-specific outputs

·         Line fault transparency (LFT)

·         Usable as signal splitter (1 input and 2 outputs)

·         Housing width 12.5 mm

·         Up to SIL 2 acc. to IEC 61508

Function :

This isolated barrier is used for intrinsic safety applications. The device transfers digital signals (NAMUR sensors or dry contacts)

from a hazardous area to a safe area. The input controls two passive transistor outputs with a resistive output characteristic.

The outputs have three defined states: 1-Signal = 6.5 V voltage drop, 0-Signal = 33 kilohm and 6.5 V voltage drop and fault > 100 kilohm.

This output characteristic offers line fault transparency on the signal lines.

Via switches the mode of operation can be reversed and the line fault detection can be switched off. A fault is signalized by LEDs acc.

to NAMUR NE44 and a separate collective error message output.
