PEPPERL+FUCHS Brand New Intrinsic Safety Barriers Isolated Barriers K-System Switch Amplifier KFD2-SR3-Ex2.2S

New & Original
KFD2-SR3-Ex2.2S
PEPPERL+FUCHS Brand New Intrinsic Safety Barriers Isolated Barriers K-System Switch Amplifier KFD2-SR3-Ex2.2S
Please contact us for more information.

PEPPERL+FUCHS Intrinsic Safety Barriers Isolated Barriers K-System Switch Amplifier KFD2-SR3-Ex2.2S





Switch Amplifier KFD2-SR3-Ex2.2S

·         2-channel isolated barrier

·         24 V DC supply (Power Rail)

·         Dry contact or NAMUR inputs

·         Usable as signal splitter (1 input and 2 outputs)

·         2 x 2 relay contact outputs with AND logic

·         Reversible mode of operation

·         Line fault detection (LFD)

·         Up to SIL 2 acc. to IEC 61508



Function :

This isolated barrier is used for intrinsic safety applications. The device transfers digital signals

(NAMUR sensors or dry contacts) from a hazardous area to a safe area.

Each input controls a relay contact output. Via switches the mode of operation can be reversed and the line fault detection can be switched off.

A fault is signalized by LEDs acc. to NAMUR NE44 and a separate collective error message output.




Selection models:

KCD2-SR-Ex1.LB                                      KCD2-SR-Ex2                                KFA6-DU-Ex1.D

KFA6-ER-Ex1.W.LB                                  KFA6-SOT2-Ex2                             KFA6-SR2-Ex1.W

KFA6-SR2-Ex1.W.LB                                KFA6-SR2-Ex2.W                           KFA6-SR2-Ex2.W.IR

KFD2-DU-Ex1.D



KFD2-ELD-Ex16                                       KFD2-ER-Ex1.W.LB                         KFD2-SH-Ex1

KFD2-SH-Ex1.T.OP                                  KFD2-SOT3-Ex1.LB                         KFD2-SOT3-Ex1.LB.IO

KFD2-SOT3-Ex2                                       KFD2-SOT3-Ex2.IO                         KFD2-SR2-Ex1.W

KFD2-SR2-Ex1.W.LB



KFD2-SR2-Ex2.W                                    KFD2-SR3-Ex2.2S                           KFD2-SRA-Ex4

KFD2-ST3-Ex1.LB                                   KFD2-ST3-Ex2                                 KHA6-SH-Ex1

KCD2-SON-Ex1                                       KCD2-SOT-Ex1.LB                           KCD2-SOT-Ex2

KCD2-SOT-Ex2.SP



KCD2-SR-Ex1.LB.SP                               KCD2-SR-Ex2.SP                             KCD2-ST-Ex1.LB

KCD2-ST-Ex2                                          KFA5-SOT2-Ex2                               KFA5-SR2-Ex1.W

KFA5-SR2-Ex1.W.LB                               KFA5-SR2-Ex2.W                             KFA5-SR2-Ex2.W.IR

KFD2-SH-Ex1.T



KFD2-SOT3-Ex2.IO-Y1                          KCD2-SON-Ex1.R1                         KCD2-SON-Ex1.SP

KCD2-SON-Ex2                                      KCD2-SON-Ex2.R1                         KCD2-SON-Ex2.SP

KCD2-SOT-Ex1.LB.SP                           KCD2-ST-Ex1.LB.SP                        KCD2-ST-Ex2.SP

KFA4-SR2-Ex2.W
