PEPPERL+FUCHS Switch Amplifier KFD2-SH-Ex1.T  Intrinsic Safety Barriers Isolated Barriers K-System

Switch Amplifier KFD2-SH-Ex1.T

1-channel isolated barrier

24 V DC supply

Input for approved dry contacts or SN/S1N sensors

Active voltage output

Relay contact output

Fault indication output

Line fault detection (LFD)

Up to SIL 3 acc. to IEC 61508

Up to PL d acc. to EN/ISO 13849

Function:

This isolated barrier is used for intrinsic safety applications. The device transfers digital signals

(SN/S1N proximity sensors or approved dry contacts) from a hazardous area to a safe area.

The input controls one active voltage output and one relay contact output with a NO contact.

Unlike an SN/S1N series proximity sensor, a mechanical contact requires a 10 kolihm resistor to be placed

across the contact in addition to a 1.5 kolihm resistor in series.

Lead breakage (LB) and short circuit (SC) conditions of the control circuit are continuously monitored.

During an fault condition, the fault indication output and the outputs I and II de-energize. For safety applications up to SIL3,

output I must be used. For safety applications up to SIL2, output I and output II can be used.
