PEPPERL+FUCHS Hot Sell ! Solenoid Driver KFD0-SD2-Ex1.10100 Intrinsic Safety Barriers Isolated Barriers K-System Solenoid Driver
- Product description
- Contact us
PEPPERL+FUCHS Solenoid Driver KFD0-SD2-Ex1.10100 Intrinsic Safety
Barriers Isolated Barriers K-System Solenoid Driver
Solenoid Driver KFD0-SD2-Ex1.10100
1-channel isolated barrier
24 V DC supply (loop powered)
Current limit 100 mA at 10 V DC
Up to SIL 3 acc. to IEC 61508
Function :
This isolated barrier is used for intrinsic safety applications. It supplies power to solenoids, LEDs, and audible alarms located in a
hazardous area. It is loop powered, so the available energy at the output is received from the input signal.
The output signal has a resistive characteristic. As a result the output voltage and current are dependent on the load and the input voltage.
At full load, 10 V at 100 mA is available for the hazardous area application.
Selection models:
KFD0-SD2-Ex1.10100
KFD0-SD2-Ex1.1180
KFD0-SD2-Ex2.1045
KFD0-SD2-Ex2.1245
KFD2-RCI-Ex1
KFD2-SL2-Ex2
KFD2-SL2-Ex2.B
KFD2-VM-Ex1.35.L
KCD0-SD3-Ex1.1045
KCD0-SD3-Ex1.1245
KCD0-SD3-Ex1.1245.SP
KCD2-SLD-Ex1.1045
KCD2-SLD-Ex1.1065
KCD2-SLD-Ex1.1245
KFD2-SLD-Ex1.13100
KCD0-SD-Ex1.1245
KCD0-SD-Ex1.1245.SP
KCD2-SLD-Ex1.1045
KCD2-SLD-Ex1.1065
KCD2-SLD-Ex1.1245
KFD0-SD2-Ex1.1045
KFD0-SD2-Ex1.1065
KFD2-SL2-Ex1
KFD2-SL2-Ex1.B
KFD2-SL2-Ex1.LK
KFD2-SL2-Ex1.LK.1045
KFD2-SL2-Ex1.LK-Y1
KFD2-SL2-Ex1.LK.1270
