HONEYWELL Sensepoint SPXCDULNN2M XCD RTD Class I, Div. 2 Explosion Proof Transmitter (4-20 mA, 3 Relays) and Sensepoint Toxic sensor

New & Original

SPXCDULNN2M

Please contact us for more information.

Sensepoint XCD RTD from Honeywell Analytics makes it easy on your maintenance team, time and budget when faced with the challenge

of monitoring toxic gases in Class I, Div. 2 areas.

You can mount the unit up to 100 ft. from the transmitter to obtain maximum gas detection coverage in areas not

easily accessible or where the sensor would not be visible, as in high-or low-level concealed areas, or detection outside the

room being monitored. XCD RTD offers unrivaled flexibility and performance via its easily recognizable display (traffic light pattern)

to convey safety status, communication and mounting options, and onboard diagnostics.

Reduce Cost of Ownership Over Life of the Product

• Cut stocking and procurement costs with a common transmitter platform

• Reduce maintenance time and expense with non-intrusive, one-man operation

• Simplify maintenance with plug-in, removable sensor

• Reduce inspection and training time with tri-color ‘traffic light’ display conveying safety status at a glance

• Simplify set-up and configuration with non-intrusive magnetic switches

Certifications

• cCSAus Ex d IIB+H2; Class I, Zone 1, AEx d IIB+H2; Class I, Div 2, Groups B, C & D

• Class I, Zone 1, AEx d ia IIC Gb; Class I, Div. 2, Groups B, C and D

• InMetro Ex d IIC T6 Gb, Ex tb IIIC T85ºC Db, IP66, -40ºC < ta < +65ºC

Gain Added Flexibility, Reliability and Performance

• Extend gas sensing element up to 100 ft. (30 m) from transmitter; mount in the most difficult to access areas

• Reduce likelihood of human error via on-board diagnostics and easy-to-read display

• Protect against dust/water ingress with IP66/67 rated stainless steel or aluminum enclosure

• Prevent false alarms with auto-inhibit during maintenance

• Select sink or source 4-20 mA output; integral or remote configuration

• Full range of accessories and purchase options let you choose the remote monitoring system that’s right for your application
