IFM IIA3015-BPKG Inductive sensor II5284 New & Original with very competitive price and One year Warranty

New & Original

IIA3015-BPKG,II5284

Please contact us for more information.

Product characteristics
Electrical design	PNP
Output function	normally open
Sensing range [mm]	15
Housing	threaded type
Dimensions [mm]	M30 x 1.5 / L = 81
Electrical data
Operating voltage [V]	10...36 DC
Current consumption [mA]	15; (24 V)
Protection class	II
Reverse polarity protection	yes
Outputs
Electrical design	PNP
Output function	normally open
Max. voltage drop switching output DC [V]	2.5
Permanent current rating of switching output DC [mA]	250
Switching frequency DC [Hz]	250
Short-circuit protection	yes
Type of short-circuit protection	pulsed
Overload protection	yes
Detection zone
Sensing range [mm]	15
Real sensing range Sr [mm]	15 ± 10 %
Operating distance [mm]	0...12.1
Accuracy / deviations
Correction factor	steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.3 / copper: 0.2
Hysteresis [% of Sr]	1...15
Switch point drift [% of Sr]	-10...10
Operating conditions
Ambient temperature [°C]	-25...80
Protection	IP 67
Tests / approvals
EMC	EN 60947-5-2EN 55011class B
MTTF [years]	1853
Mechanical data
Weight [g]	263
Housing	threaded type
Mounting	non-flush mountable
Dimensions [mm]	M30 x 1.5 / L = 81
Thread designation	M30 x 1.5
Materials	brass white bronze coated; sensing face: PBT
Displays / operating elements
Display	switching status1 x LED, yellow
Accessories
Accessories (supplied)	lock nuts: 2
Remarks
Pack quantity	1 pcs.
Electrical connection
Connection	Cable: 2 m, PVC; 3 x 0.5 mm²
