PEPPERL+FUCHS KFD2-GUT-Ex1.D Temperature Converter with Trip Values Intrinsic Safety Barriers Isolated Barriers K-System Signal Converters

New & Original

KFD2-GUT-Ex1.D

Please contact us for more information.

PEPPERL+FUCHS Temperature Converter with Trip Values KFD2-GUT-Ex1.D

Intrinsic Safety Barriers Isolated Barriers K-System Signal Converters

Features :

• 1-channel isolated barrier

• 24 V DC supply (Power Rail)

• Thermocouple, RTD, potentiometer or voltage input

• Redundant TC input

• Current output 0/4 mA ... 20 mA

• 2 relay contact outputs

• Configurable by PACTware or keypad

• Line fault (LFD) and sensor burnout detection

• Up to SIL 2 acc. to IEC 61508/IEC 61511

Function :

This isolated barrier is used for intrinsic safety applications.

The device converts the signal of a resistance thermometer, thermocouple, potentiometer, or voltage source to a

proportional output current. It also provides a relay trip value.

The removable terminal block K-CJC-** is available as an accessory for internal cold junction compensation of thermocouples.

A fault is signalized by LEDs acc. to NAMUR NE44 and a separate collective error message output.

The device is easily configured by the use of the PACTware configuration software

KFD2-GUT-Ex1.D details
