In stock HIRSCHMANN MACH102-8TP-FR Workgroup Switches ,Fast-/Gigabit Ethernet Workgroup Switches, 10/24 ports New & Original with very competitive price and One year Warranty

New & Original
MACH102-8TP-FR ,943 969-301
In stock HIRSCHMANN MACH102-8TP-FR Workgroup Switches ,Fast-/Gigabit Ethernet Workgroup Switches, 10/24 ports New & Original with very competitive price and One year Warranty
Please contact us for more information.

HIRSCHMANN MACH102-8TP-FR Workgroup Switches ,Fast-/Gigabit Ethernet Workgroup Switches, 10/24 ports




Product description

Description

10 port Fast Ethernet/Gigabit Ethernet Industrial Workgroup Switch (2 x GE, 8 x FE), managed, Software Layer 2 Professional,

Store-and-Forward-Switching, fanless Design, redundant power supply


Type

MACH102-8TP-FR


Order No.

943 969-301


Port type and quantity

10 ports in total; 8x (10/100 BASE-TX, RJ45) and 2 Gigabit Combo ports


More Interfaces

Power supply/signaling contact

1 x plug-in terminal block, 2-pin, output manual or automatic switchable (max. 1 A, 24 V DC bzw. 24 V AC)


V.24 interface

1 x RJ11 socket, serial interface for device configuration


USB interface

1 x to connect auto-configuration adapter ACA21-USB


Network size - cascadibility

Line - / star topology

any

Ring structure (HIPER-Ring) quantity switches

50 (reconfiguration time < 0,3 sec.)


Power requirements

Operating voltage: 100 - 240 VAC, 47 - 63 Hz (redundant)

Power output in Btu (IT) h: 44

Rated current: 0.4 - 0.2 A

Power consumption: 13 W


Ambient conditions

Operating temperature: 0° - +50°C

Storage/transport temperature: -20° - +85°C

Relative humidity (non-condensing): 10% to 95%

MTBF: 18,06 years (MIL-HDBK-217F Gb 25°C)


Mechanical construction

Dimensions (W x H x D): 448 x 44 x 310 (without fixing bracket)

Mounting: 19" control cabinet

Weight: 3.85 kg

Protection class: IP20


Model No

Fast-/Gigabit Ethernet Workgroup Switches, 10/24 ports

MACH102-8TP-FR

MACH102-8TP

MACH102-8TP-F

MACH102-24TP-F

MACH102-24TP-FR

MACH102-8TP-R


Gigabit Ethernet Industrial Workgroup Switches, 24 Ports

MACH104-20TX-F

MACH104-20TX-FR

MACH104-20TX-F-L3P

MACH104-20TX-FR-L3P


Gigabit/10 Gigabit Ethernet PoE Workgroup Switches, 22-24 Ports

MACH104-16TX-PoEP

MACH104-16TX-PoEP +2X -R-L3P

MACH104-16TX-PoEP-L3P

MACH104-16TX-PoEP +2X -E

MACH104-16TX-PoEP +2X

MACH104-16TX-PoEP +2X -E-L3P

MACH104-16TX-PoEP -E

MACH104-16TX-PoEP +2X -R

MACH104-16TX-PoEP-E-L3P

MACH104-16TX-PoEP -R

MACH104-20TX-F-4PoE

MACH104-16TX -PoEP-R-L3P

MACH104-20TX-F-4PoE-L3P
