IN STOCK PEPPERL + FUCHS SMART Current Driver HiC2031 New & Original

100% New & Original with very competitive price and One year Warranty
HiC2031
IN STOCK PEPPERL + FUCHS SMART Current Driver HiC2031 New & Original
Please contact us for more information.

IN STOCK PEPPERL + FUCHS SMART Current Driver HiC2031 New & Original



1-channel isolated barrier

24 V DC supply (bus powered)

Current output up to 650 Ω load

Low power dissipation

Up to SIL 2 acc. to IEC 61508


Datasheet

Signal type Analog output

Safety Integrity Level (SIL) SIL 2

Supply

Connection SL1: 1a(-), 1b(-); 2a(+), 2b(+)

Rated voltage 19 ... 30 V DC bus powered via Termination Board

Ripple ≤ 10 %

Rated current ≤ 30 mA

Power dissipation ≤ 600 mW

Power consumption ≤ 700 mW


Input

Connection side control side

Connection SL1: 8a(+), 7a(-)

Input signal 4 ... 20 mA limited to approx. 30 mA

Input voltage depending on switch configuration

open loop voltage of the control system < 23 V

open loop voltage of the control system < 27 V

Voltage drop depending on switch configuration

open loop voltage of the control system < 23 V: approx. 6 V at 20 mA

open loop voltage of the control system < 27 V: approx. 10 V at 20 mA

Input resistance > 100 kΩ, with field wiring open


Output

Connection side field side

Connection SL2: 5a(+), 5b(-)

Current 4 ... 20 mA

Load 0 ... 650 Ω

Voltage ≥ 13 V at 20 mA

Ripple 20 mV rms


Indicators/settings

Display elements LED

Control elements DIP-switch

Configuration via DIP switches

Labeling space for labeling at the front


Selection models:

KFD0-SD2-Ex1.10100

KFD0-SD2-Ex1.1180

KFD0-SD2-Ex2.1045

KFD0-SD2-Ex2.1245

KFD2-RCI-Ex1

KFD2-SL2-Ex2

KFD2-SL2-Ex2.B

KFD2-VM-Ex1.35.L

KCD0-SD3-Ex1.1045

KCD0-SD3-Ex1.1245

KCD0-SD3-Ex1.1245.SP

KCD2-SLD-Ex1.1045

KCD2-SLD-Ex1.1065

KCD2-SLD-Ex1.1245

KFD2-SLD-Ex1.13100

KCD0-SD-Ex1.1245

KCD0-SD-Ex1.1245.SP

KCD2-SLD-Ex1.1045

KCD2-SLD-Ex1.1065

KCD2-SLD-Ex1.1245

KFD0-SD2-Ex1.1045

KFD0-SD2-Ex1.1065

KFD2-SL2-Ex1

KFD2-SL2-Ex1.B

KFD2-SL2-Ex1.LK

KFD2-SL2-Ex1.LK.1045

KFD2-SL2-Ex1.LK-Y1

KFD2-SL2-Ex1.LK.1270


HiC2031
