FLUKE 1623-2 GEO Earth Ground Resistance Meter Brand New

Key features

A unique earth ground tester that performs fast, accurate testing with and without stakes

Tests 3- and 4-pole fall-of-potential, and 4-pole soil resistivity (with stakes)

Performs selective earth ground rod testing (one clamp + stakes)

Performs stakeless earth ground rod testing (two clamps)

Features IP56 rating for outdoor use

Product overview: Fluke 1623-2 GEO Earth Ground Resistance Meter

Fluke 1623-2 Earth Ground Tester performs all four ground tests quickly and accurately.

The Fluke 1623-2 earth ground tester measures earth ground loop resistances using only clamps, only stakes, or one clamp and stakes.

With the stakeless test method, the Fluke 1623-2 is able to measure earth ground loop resistances for multi-grounded systems using only current clamps.

This technique eliminates the dangerous, and time consuming job of disconnecting parallel grounds,

and finding suitable locations for auxiliary ground stakes.

You can use it to perform earth ground tests in places you’ve not considered before, such as inside buildings,

on power pylons, or anywhere you don’t have access to soil.

Keep your options open

Keep in mind, the stakeless test method works only if a bonded earth ground system exists for the building or structure under test.

If there is only one path to ground, typical with many residential applications, you will need to use the fall-of-potential test method that requires stakes.

The 1625-2 is also very easy to use. World class accessories speed set up and test time.

And the tester tells you which stakes or clamps to connect for each test.

The large rotary switch and buttons are easy to operate even with a gloved hand. And you can store up to 1,500 records and access them easily via the USB port.

Need even more accuracy? Check out the 1625-2 that offers:

Automatic Frequency Control that identifies existing interference and chooses a measurement frequency to minimize its effect,

thus providing a more accurate earth ground value. R* measurement that calculates earth ground impedance at 55 Hz to

more accurately reflect the earth ground resistance that a fault-to earth ground would see.

Other useful capabilities:

Includes USB port for data storage and transfer

Works with world class that speed set up and test time

Comes with a rugged carrying case

Models: Fluke 1623-2 GEO Earth Ground Resistance Meter

Includes:

GEO Earth Ground Tester

User's Manual

Batteries

Quick Reference Guide

2 Test Leads

USB Cable

Specifications: Fluke 1623-2 GEO Earth Ground Resistance Meter

General Specifications

Display: 1999 digit LCD Display with special symbols, digit height 25 mm, fluorescent backlight

User interface Instant measurement through TURN and START one button concept.

The only operating elements are rotary switch and START button

Robust, water and dust resistant Instrument is designed for tough environmental conditions (rubber protective cover, IP56)

Memory Internal memory storage up to 1500 records accessible via USB port

Temperature Range

Operating temperature -10°C to 50°C (14°F to 122°F)

Storage temperature -30°C to 60°C (-22°F to 140°F)

Temperature coefficient ±0.1% of reading/°C < 18°C > 28°C
