In stock Danfoss Thermo. operated water valve, AVTA 15 003N2162 New & Original

New & Original very competitive price with One Year Warranty
003N2162
In stock Danfoss Thermo. operated water valve, AVTA 15 003N2162 New & Original
Please contact us for more information.

Danfoss Thermo. operated water valve, AVTA 15 003N2162



Product name: Thermo. operated water valve

Type: AVTA 15

Connection type: G

Connection Internal/External: Internal

Kv value [m³/h]: 1.900

Charge type: Universal


Product details

Gross weight 1.67 kg

Net weight 1.34 kg

EAN 5702423004157

Cap. tube length fraction [in] 78 3/4 in

Capillary tube gland Int/Ext Internal

Capillary tube gland size [in] 3/4

Capillary tube gland standard ISO 228-1

Capillary tube gland type G

Differential pressure [bar] [Max] 10 bar

Differential pressure [bar] [Min] 0 bar

Differential pressure [psi] [Max] 145 psi

Differential pressure [psi] [Min] 0 psi

Equipment Bracket

Flow direction indicator Embossed 1-way arrow

Identical product 003N5052

Kv value [m³/h] 1.9 m3/h

Max. pressure on sensor [bar] 25 bar

Max. pressure on sensor [psig] 362.6 psig

Max. sensor temperature [°C] 90 °C

Max. sensor temperature [°F] 194 °F

Max. test pressure [bar] Pe 25 bar

Max. test pressure [psig] 362.6 psig

Max. Working Pressure [bar] 16 bar

Max. Working Pressure [psig] 232 psig

Media Neutral media

Medium temperature range [°C] [Max] 130 °C

Medium temperature range [°C] [Min] -25 °C

Medium temperature range [°F] [Max] 266 °F

Medium temperature range [°F] [Min] -13 °F

Opening configuration Opens on rising sensor temp.

Orifice size [mm] 15 mm

Orifice size fraction [in] 3/5 in

Packing format Multi pack

Product accessories Generic accessories

Water valves accessories

Product description Thermostatic valve

Product family name AVTA

Product group Water regulating valves

Product name Thermo. operated water valve

Quantity per packing format 10 pc

Sensor size (Ø x L) [in] 23/32 x 8 1/4 in

Sensor size (Ø x L) [mm] 18 x 210 mm

Serviceable Water valve spare parts

Temperature range [°C] [Max] 65 °C

Temperature range [°C] [Min] 25 °C

Temperature range [°F] [Max] 149 °F

Temperature range [°F] [Min] 77 °F

Type AVTA 15


003N2162 details1


003N2162 details2


003N2162 details3


003N2162 details4
