IN STOCK Schneider LV431536 Vigi add-on protection module Brand New with Good Discount

100% New & Original with very competitive price and One year Warranty

LV431536

Please contact us for more information.

Schneider LV431536 Vigi add-on protection module

Compact NSX 250, EasyPact CVS 250, MH type, 200 VAC to 440 VAC, 30 mA to 10 A, 4 poles

Main

product or component type: Vigi add-on

device application : Wiring

range compatibility

Compact NSX250 circuit breaker

Easypact CVS250 circuit breaker

poles description : 4P

[In] rated current: 250 A

earth-leakage add-on module name : MH

earth-leakage protection class : Class A

residual earth-leakage sensitity adjustment type : Adjustable 5 settings

earth-leakage sensitivity

0.03 A

0.3 A

1 A

3 A

10 A

residual earth-leakage time delay adjustment type : Adjustable 4 settings

[Δt] residual earth-leakage time delay adjustment

0 ms

310 ms

60 ms

150 ms

Complementary

network type : AC

network frequency : 50/60 Hz

[Ue] rated operational voltage : 200...440 V AC 50/60 Hz conforming to IEC 60947-2

earth-leakage protection : With

maximum breaking time : 800 ms

overvoltage category : Class II
