NEWEST Schneider ATS48C21Q Soft starter Brand New with Good Discount
- Product description
- Contact us
Schneider ATS48C21Q Soft starter
Soft starter for asynchronous motor - ATS48 - 195 A - 230..415 V - 45..160 KW
Main
range of product : Altistart 48
product or component type : Soft starter
product destination : Asynchronous motors
product specific application : Heavy duty industry and pumps
device short name : ATS48
power supply voltage : 230...415 V - 15...10 %
Complementary
assembly style : With heat sink
function available : External bypass (optional)
power supply voltage limits : 195…456 V
power supply frequency : 50...60 Hz - 5...5 %
power supply frequency limits : 47.5...63 Hz
device connection : To the motor delta terminals
In the motor supply line
factory setting current : 195 A
[Uc] control circuit voltage : 220 - 15 % to 415 + 10 %, 50/60 Hz
control circuit consumption : 50 W
height : 380 mm
width : 320 mm
depth : 265 mm
net weight : 18.2 kg
There have More Schneider items , all for 100% New & Original with very good discount , pls kindly contact with Chris directly to know more details information .
Chris Fang
Sales Engineer
Sunup (Wuhan) Import and Export Co., Ltd.
Add:7-A16,Caishen Commercial Plaza,Hankou Railway Station,Wuhan, China
Postal code:430015
M: + 86-15926376631(WhatsApp & Wechat) |
Skype: live:chris_61491
Email: chris@sunupauto.com
Web: http://www.sunup-automation.com
