SIEMENS SITRANS F M MAG 5000 microprocessor-based transmitter
The SITRANS F M MAG 5000 is a microprocessor-based transmitter, which is a truly robust all-around solution for a wide variety of applications.
The MAG 5000 is transmitters engineered for high performance, easy installation, commissioning and maintenance.
The transmitters evaluate the signals from the SITRANS F M sensors type MAG 1100, MAG 1100 F, MAG 3100, MAG 3100 P and MAG 5100 W.
Transmitter types:
MAG 5000: Max. measuring error ± 0.4 % ± 1 mm/s (incl. sensor)
Benefits
Superior signal resolution for optimum turn down ratio
Digital signal processing with many possibilities
Automatic reading of SENSORPROM data for easy commissioning
User configurable operation menu with password protection
3 lines, 20 characters display in 11 languages
Flow rate in various units
Totalizer for forward, reverse and net flow as well as additional information available
Multiple functional outputs for process control, minimum configuration with analogue, pulse/frequency and relay output (status, flow direction, limits)
Comprehensive self-diagnostic for error indication and error logging (see SITRANS F M diagnostics)
Batch control (MAG 6000 only)
Custody transfer approval: PTB, OIML R 75, OIML R 117, OIML R 49, MI-001, PTB K 7.2 and OE12/C 040 for chilled water
MAG 6000 with add-on bus modules for HART, FOUNDATION Fieldbus H1, DeviceNet, Modbus RTU/RS485, PROFIBUS PA and DP
Application
The SITRANS F M flowmeters are suitable for measuring the flow of almost all electrically conductive liquids,
pastes and slurries. The main applications can be found in:
Water and waste water
Chemical and pharmaceutical industries
Food and beverage industries
Power generation and utility
Design
The transmitter is designed as either IP67 NEMA 4X/6 enclosure for compact or wall mounting or 19" version as a 19" insert as a base to be used in:
19" rack systems
Front panel mounting IP65/NEMA 2
Panel mounting IP20/NEMA 1
Wall mounting IP66/NEMA 4X
Several options on 19" versions are available such as:
Transmitters mounted in safe area for Ex ATEX approved flow sensors (incl. barriers)
Transmitters with electrode cleaning unit on request
