PEPPERL+FUCHS 100% New & Original Solenoid Driver KCD0-SD3-Ex1.1245 Intrinsic Safety Barriers Isolated Barriers K-System Solenoid Driver

New & Original
KCD0-SD3-Ex1.1245
PEPPERL+FUCHS 100% New & Original Solenoid Driver KCD0-SD3-Ex1.1245 Intrinsic Safety Barriers Isolated Barriers K-System Solenoid Driver
Please contact us for more information.

PEPPERL+FUCHS Solenoid Driver KCD0-SD3-Ex1.1245 Intrinsic Safety Barriers Isolated Barriers

K-System Solenoid Driver




Solenoid Driver KCD0-SD3-Ex1.1245


1-channel isolated barrier

24 V DC supply (loop powered)

Current limit 45 mA at 12 V DC

 Test pulse immunity

Housing width 12.5 mm

Up to SIL 3 acc. to IEC 61508



Function :

This isolated barrier is used for intrinsic safety applications. The device supplies power to solenoids,

LEDs and audible alarms located in a hazardous area. The device is loop powered, so the available energy

at the output is received from the input signal. The output signal has a resistive characteristic.

As a result the output voltage and current are dependent on the load and the input voltage At full load,

12 V at 45 mA is available for the hazardous area application.




KCD0-SD3-Ex1.1245 .JPG

Selection models:

KFD0-SD2-Ex1.10100

KFD0-SD2-Ex1.1180

KFD0-SD2-Ex2.1045

KFD0-SD2-Ex2.1245

KFD2-RCI-Ex1

KFD2-SL2-Ex2

KFD2-SL2-Ex2.B

KFD2-VM-Ex1.35.L

KCD0-SD3-Ex1.1045

KCD0-SD3-Ex1.1245

KCD0-SD3-Ex1.1245.SP

KCD2-SLD-Ex1.1045

KCD2-SLD-Ex1.1065

KCD2-SLD-Ex1.1245

KFD2-SLD-Ex1.13100

KCD0-SD-Ex1.1245

KCD0-SD-Ex1.1245.SP

KCD2-SLD-Ex1.1045

KCD2-SLD-Ex1.1065

KCD2-SLD-Ex1.1245

KFD0-SD2-Ex1.1045

KFD0-SD2-Ex1.1065

KFD2-SL2-Ex1

KFD2-SL2-Ex1.B

KFD2-SL2-Ex1.LK

KFD2-SL2-Ex1.LK.1045

KFD2-SL2-Ex1.LK-Y1

KFD2-SL2-Ex1.LK.1270
